Invite nature into your building

GEMI 77.PD combines high insulation and comfort with maximal transparency and aesthetics. This folding door system optimizes your way of living by drawing the exterior into your home, with a minimum of space usage. This high performance system offers different opening types, both inward and outward, to meet all possible requirements.

About

People are continuously looking for ways to maximize their space, as well visually as physically. The GEMI 77.PD offers them the opportunity to optimize the utilization of their rooms, drawing the external environ- ment into their homes. Next to the improved space utilization, this innovative system offers the advantage of loads of daylight coming in, as well as an aesthetical design. Another practical feature of GEMI 77.PD is the optional door locking principle which allows to use the rst leaf as an entrance door without affecting the folding capacity of the system.

GEMI 77.PD combines high insulation and comfort with maximal transparency and aesthetics. This folding door system optimizes your way of living by drawing the exterior into your home, with a minimum of space usage. This high performance system offers different opening types, both inward and outward, to meet all possible requirements. Apart from the standard folding elements, GEMI 77.PD can feature a main door principle, in which the first leaf is used as an entrance door without affecting the other folding leafs.

GEMI 77.PD is available in 4 different threshold solutions, from high performance to low and even flush thresholds, in order to perfectly match all comfort and aesthetic requirements. Additionally, the GEMI 77.PD-concept can perfectly be combined with the CS systems for windows, doors and curtain walls.

Request Product Catalog

Slimmer profile available

Next to the functional design, the CF 77 is supplemented with a Slim-Line variant, the CF 77-SL, featuring a narrower visible width. Both designs are available in four different door sill solutions:
High Performance, Double Weather Seal, Low Threshold and Flat Bottom Solution.

The High Performance option offers maximum performance in terms of air, wind and water resistance. The Double Weather Seal solution combines good air, wind and water resistance with decreased threshold and is well suited for renovation projects. The Low Threshold option offers a rise of only
18 mm and nally the Flat Bottom solution allows easy passage and maximum convenience for high traf c.

4 different threshold solutions

*The burglar proof classification is in accordance with EN 1627-1630.

Properties

Highly thermally insulating

Water resistance up to 600 Pa

The High Performance option offers maximum performance in terms of air, wind and water resistance.

Glazing up to 63mm

2 to 8 vent combinations

Available in a number of configurations using between 2 and 8 door leaves, you can choose a design where the complete set of vents stacks to the same side, or split the design at any position, possibly integrating a central door solution.

Burglar resistant variant

RC2 burglar proof classification in accordance with EN 1627-1630

Technical Specification

Profile chambers 3
Construction depth 85mm / 3" 3/8
Glasses 2 / 3
Glazing type 4-16-4 / 4-12-4-12-4
U (window) 0.27 (U.S/I-P, double glazing)
0.20 (U.S/I-P, triple glazing)
U (glass) 0.18 (U.S/I-P, double glazing)
0.10 (U.S/I-P, triple glazing)
Min width -
Min height -
Max width 1200mm per vent
Max height 3000mm per vent
Sound mitigation (Rw) based on glazing and size -

Compare Window Download Product Catalog

I Want to Know More

    Features

    Design and Style

    Prevention effect, advocate dialogue rural development lifting people up community civil society. Catalyst, grantees leverage.

    Superior Thermal Insulation

    Prevention effect, advocate dialogue rural development lifting people up community civil society. Catalyst, grantees leverage.

    Sound Mitigation

    Prevention effect, advocate dialogue rural development lifting people up community civil society. Catalyst, grantees leverage.

    Accessories

    Prevention effect, advocate dialogue rural development lifting people up community civil society. Catalyst, grantees leverage.
